General information：
The route to efficient yarn dyeing starts in the laboratory and with small scale production.
The SamY Eco-Dye meets both these requirements while maintaining maximum flexibility with minimum consumption.
Technical details：
- High efficiency, high performance centrifugal pump
- Flexible loading 1-3, 3-4 packages
- All liquor-carrying parts are manufactured using stainless steels 316L
- Max. working pressure: 0.44Mpa
- Max. working temperature: 140℃
- Heating rate: 20~130 about 30 minutes (Saturated steam pressure 0.7Mpa)
- Cooling rate: 130~80 about 20 minutes (cooling water pressure 0.3Mpa)
- Standard spindle dia. Is φ48mm
- Standard package size is φ165mm,height 160mm, weight is calculated as 1kg per cone
- Machine fully Automatic control by SETEX controller + Setex PLC - And machine Automatic and Manual everything Control from main Electric cabinet
Optional ：
- Hot water stock tank, preparation of the complete process bath
- Second service tank
- Extra carrier
- Progressive dosing system
- Secondary water feeding and draining
- Accessories for dyeing, such as cone, intermediate gasket and self falling locker
- Unloading device
|
 |
Product Name: SamY Eco-Dye  |
